HPT-3 Intelligent Pressure Transmitter with Hart and RS485 output

Brand Name : HT

Model Number : HPT-3

Place of Origin : China

MOQ : 1pcs

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1000pcs/day

Packaging Details : 1pcs /box , Standard Exporting packing

Output signal : 4-20mA,0-10V,RS485 ,RS232

Protocol : Hart protocol

Display : 4 digit LCD Display

Contact Now

PROFESSIONAL PRESSURE ,LEVEL,TEMPERATURE TRANSMITTER SOLUTION PROVIDER

Instruction:

HPT-3 intelligent pressure transmitter is an intelligent pressure measurement product with high accuracy, high
stability, multi-parameter and four digits LCD display. It conforms to Hart protocol.
The product uses the most advanced digital technique, and reliable ex-proof construction for production and
whole product has high accuracy, and local display indictor could be widely used on pressure measure in outdoor
application, such as petroleum, chemi-industry, metallurgy and power station, etc.
For signal output 4-20mA,RS485 and RS232 are optional

Features:
Ø 4 digit LCD Display
Ø Fully digital signal processing
Ø RS485/RS232 connection ( Up to 512 nodes )
Ø Anti electromagnetic interference Design
Ø Suitable for harsh environment

Applications:
Ø Hydraulic/Pneumatic Control Systems
Ø Chemical
Ø Power Generation
Ø Process control
Ø Oil and gas

HPT-3 Intelligent Pressure Transmitter with Hart and RS485 output

HPT-3 Intelligent Pressure Transmitter with Hart and RS485 output Images
